Known for dimensional accuracy, these machines come equipped with 3-axis automatic movement with incremental downfeed, electronic auto-crossfeed, and proportional valve hydraulic powered table movement. They also feature a full-featured electronic control with glass-scale closed loop feedback on Z-axis.
Specifications
SGS-1020AHD
Working Capacity 10" x 20"
Table Travel 22.2"
Saddle Travel 10.3"
T-Slot 1 x 9/16”
Spindle Motor 2 HP
Spindle Speed 3500 RPM
Grinding Wheel 8” x ½” x 1¼”
Vertical Graduation 0.0005"
Vertical Revolution 0.100"
Auto Downfeed Increment 0.0001" 10 Steps
Spindle to Table 19.6"
Net Weight 2970 LBS
Gross Weight 3520 LBS
Standard Accessories
Grinding wheel
Wheel Flange
Wheel balancing base
Wheel balancing arbor
Diamond table dresser base & tip
Leveling bolts & pads
Overhead parallel dresser
Dust-suction coolant system
Permanent chuck
Work light
Toolbox with tools
