New LEADWELL LTC-35LM | CNC Lathes

Description

MORE POWERFUL
*Powerful main spindle 40HP
*Rigid 45 deg. Slant bed cast iron base
INCREASED CAPACITY
*15 inch chuck standard
*115mm bar capacity standard
FASTER/MORE PRODUCTIVE
*Fast rapid rates 15~20m/min
*Spindle speed 2000rpm
*C axis and VDI 60&BMT 75 live tooling version available
ERGONOMIC CONSIDERSATIONS
*Easy to use membrane touch-pad control station
*Easy moving operator door
*Parts catcher available
*No chip or coolant leaks

Max. turning diameter
mm (in) 494(19.4)/520(20.5) BMT75
Max. turning length
mm (in) 1030/1530/2030/3006/4006(40.6/60.2/79.9/118.3/157.7)
Bar capacity mm (in) 115(4.5)
X axis travel mm (in) 344+10(13.5+0.39)/290+20(11.4+0.8)BMT75
Z axis travel mm (in)
1100/1600/2100/3100/4100
(43/63/83/122/161)
